CanNeed-AMG-300
Aerosol Measuring Gauge

Testing occasions：laboratory

Detection object：Three-piece can/spray can

Test items：Dimensions

Applications

The CanNeed AMG-300 Aerosol Measuring Gauge is a Convenient Gauge for Aerosol Cans, it can measures 6 characteristics in 1 compact Gauge. measures the following characteristics:

1) Can Height over all (E)

2) Can Height over the seams (D)

3) Can height between the seams (F)

4) Top Outside Diameter (K),

5) Top seam Outside Diameter

6) Bottom seam Outside Diameter

The CanNeed AMG-300 saves valuable time and table space. Combine five essential aerosol can gauges into one convenient measurement Gauge.

Advantages

1) Require little training and is extremely easy to use;

2) Produce measurements with extremely high repeatability and reproducibility;

3) Hands-Free design replaces individual, manual gauges and eliminates measurement variation as the result of operator interference.

Technical Parameter

Model	AMG-300	AMG-500
Measure range	0 - 300 mm	0 - 500 mm
Long	590 mm	790 mm
Width	630 mm	630 mm
Height	400 mm	400 mm
weight	33 kg	39 kg
Resolution	0.005 mm
Accuracy (20°C):	± 0.02mm
Power supply	85-230 V , 50-60Hz
